210 Watt Dimmable Rectangular LED High Bay | Silver Series | 27,300 Lumen, 5000k (Daylight), 120-277 Volts

SKU: HR4-273-210-50U-S2

Availability: 48 in stock

save or share this page
Share on facebook
Share on linkedin
Share on twitter
Share on reddit
Share on email
Share on print

Product Overview

 Touch-Plate’s Silver Series 210 Watt LED Rectangular High Bay is designed for a variety of indoor applications. With energy savings of 70% or greater over traditional lighting. Touch-Plate’s Rectangular High Bay LED Lights are a great solution for both new construction and replacing outdated fixtures.

Touch-Plate’s LED Model: HR4-273-210-50U-S2

is a 210 Watt, Rectangular LED High Bay. It provides 27,300 Lumens of Light at 5000k (Daylight) Color Temperature.

Features:
  • Steel Frame Body
  • Flicker-Free
  • Isolated Driver
  • Multiple Mounting Options Available
  • 0-10v dimming capable
  • UL & DLC Premium Listed
  • 50,000 Hour Rated
  • 5 Year Limited Warranty
Accessories: (call to order)
  • Wire Guard
  • Emergency Back-up
  • Occupancy Sensor
  • Zigbee: Relay, Dimmer & Controller
  • Stainless Steel Cable: 2 feet (.5 meter) / 3 feet (1 meter) / 7 feet (2 meters) / 10 feet (3 meters) / 20 feet (6 meters)
  • Lock Twist Plug: 3 feet (1 meter) / 10 feet (3 meters)
  • No Plug Extension: 3 feet (1 meter) / 10 feet (3 meters)
  • USA 3 Prong Plug: 7 feet (2 meters)
  • S Hook Clip: Medium / Large
  • Stainless Steel Magnetic ‘O’ Hook

DOWNLOADS

Specification Sheet:
Photometrics:

COLOR TEMPERATURE

CERTIFICATIONS

TOUCH-PLATE'S LED GUARANTEES

specifications

PRODUCT DETAILS

Manufacturer Part Number:

HR4-273-210-50U-S2

DLC Listed:

Yes

Manufacturer:

Touch-Plate

UL Listed:

Yes

Warranty:

5 Years (Limited Liability)

ETL Listed:

-

Rated Hours:

50,000 hours

LIGHT OUTPUT

Lumens: (total brightness)

27300 lm

Color Temperature: (CCT)

5000k (Daylight)

Wattage: (energy consumption)

210w

CRi: (color accuracy)

>80Ra

Lumens per Watt: (lm/w)

130 lm/w

Lens Type:

Milky Plastic

Equivalent Replacement: (non-led)

600w HID/HPS/MH

Beam Angle:

90°

FEATURES

Lamp Type:

LED

Product Color:

White

LED Chipset:

LG5630

Product Material:

Steel Body Frame

Dimmable:

0-10v Dimming

PF Rating: (power factor)

>0.9

Input Voltage:

120-277v

IP Rating: (water proofing)

IP65

Minimum Operating Temperature:

-

IK Rating: (surge protection)

-

Maximum Operating Temperature:

-

Special Features:

• Flicker Free

• Isolated Driver

• Multiple Mounting Options

• Aluminum LED Board Heat Sink

• 0-10v Dimming

DIMENSIONS

Height:

3.50 in

Diameter:

-

Width:

23.82 in

Length:

45.90 in

Weight:

13.50 lbs
