20 Watt LED Flood Light | Silver Series | 2,000 Lumens, 5000K (Daylight), 120-277 Volts

SKU: FDL-020-020-50U-T-S9

Availability: 15 in stock

save or share this page
Share on facebook
Share on linkedin
Share on twitter
Share on reddit
Share on email
Share on print

Product Overview

Touch-Plate’s Silver Series
20 Watt LED
Flood Light

is designed for a variety of applications and environments. With energy savings of 70% or greater over traditional lighting. Touch-Plate’s Flood Light LED Lights are optimal for both retrofit upgrade projects and new construction.

Touch-Plate’s LED Model: FDL-020-020-50U-T-S9
a 20 Watt, LED Flood Light. Producing 2000 lumens of light,

at a 5000k (Daylight) color temperature.

Features:

• Slim Design

• Uniform Light

• Tempered Glass

• 270° rotate bracket

UL & DLC Listed
50,000 Hour Rated
5 Year Limited Warranty

Accessories: (call to order)
• Wire Guard
• Diffuser
• Occupancy Sensor
• Photocontrol Sensor
• Zigbee: Relay, Dimmer, Controller
• Stainless Steel Cable: 2 feet/3 ft / 7 ft / 10 ft/ 20 ft
• Twist Lock Plug: 3 ft / 10 ft
• No Plug Extension: 3 ft / 10 ft
• (US Standard) 3 Prong Plug: 7 ft
• S Hook Clip: Medium / Large
• Connection Box: Small / Large
• Connector: 3-Pin Splice

DOWNLOADS

Specification Sheet:
Photometrics:

COLOR TEMPERATURE

CERTIFICATIONS

TOUCH-PLATE'S LED GUARANTEES

specifications

PRODUCT DETAILS

Manufacturer Part Number:

FDL-020-020-50U-T-S9

DLC Listed:

Yes

Manufacturer:

Touch-Plate

UL Listed:

Yes

Warranty:

5 Years (Limited Liability)

ETL Listed:

-

Rated Hours:

50,000 hours

LIGHT OUTPUT

Lumens: (total brightness)

2000 lm

Color Temperature: (CCT)

5000k (Daylight)

Wattage: (energy consumption)

20w

CRi: (color accuracy)

>80Ra

Lumens per Watt: (lm/w)

100 lm/w

Lens Type:

Clear Glass

Equivalent Replacement: (non-led)

60w A19/BR/PAR/CFL

Beam Angle:

120°

FEATURES

Lamp Type:

LED

Product Color:

Black

LED Chipset:

Philips Lumileds 3030

Product Material:

Die-cast Aluminum

Dimmable:

None

PF Rating: (power factor)

>.98

Input Voltage:

120-277v

IP Rating: (water proofing)

IP65

Minimum Operating Temperature:

-

IK Rating: (surge protection)

-

Maximum Operating Temperature:

-

Special Features:

• Slim Design

• Uniform Light

• Tempered Glass

• 270° rotate bracket

DIMENSIONS

Height:

1.5 in

Diameter:

-

Width:

5.3 in

Length:

7.87 in

Weight:

3.5 lbs
